Automatic Labeling Machine

Small round bolttle adhesive labeling machine

SPECIFICATIONS FOR FRS-PWMA High Speed Horizontal Type Adhesive Labeling Machine
Model
FRS-PWMA
Labeling speed
60-260pcs/min
Driving Mode
Servo control system
The size of bottle
OD:12-24mm,Height:25-95mm
The size of label
Height 20-70mm Length 25-80mm
The inner diameter of label volume (mm)
76mm
The outer diameter of label volume (mm)
350mm(max)
Power of motor (w)
300W
Power supply
350mm (max)
The power of motor
300W
Voltage
AC220V 50/60HZ single phase
Dimension (mm)
1800*700*1270mm
Weight of machine
400kg

Main Features

1) The whole machine adopts mature technology PLC control system, so that the operation of the machine is stable and high-speed;
2) Operating system adopts touch screen control, simple, practical and efficiently;
3) Use imported servo motor, the speed of outing label is fast and location is accurate;
4) Input type rolling objects, so that labels attached to a more solid.
5) The whole machine is made of S304 stainless steel and the anode handling superior aluminum. Never rust, high corrosion resistance
6) Function: no objects no labeling, automatic alarming or removing (optional device) when labeling without labels or no labeling.
7) With the ribbon typer,can print the date in the label
