The hydraulic press is a working mechanism with the hydraulic compment and hydraulic cylinders,the moving board is driven by the control system to achieve the purpose of work.The number of strokes per minute and the movement stroke of the movable plate can be adjusted. The hydraulic machine is suitable for bath, hardware, electronics, rubber, plastic products such as cutting, punching, blanking, cutting, bending and stretching half cut etc.. Such as the automatic feeding mechanism of the device, the semi-automatic work can be carried out. The machine is sturdy and durable easy to move,the stainless steel and aluminum alloy are especially resistant to corrosion. Its open structure makes the mold installation and adjustment very convenient. The electrical system is controlled by PLC, with simple operation and stable performance.
Parameters:
Structural material of stainless steel 304 alloy aluminum
The area of the working platform is 600 * 600mm
Using voltage:220v,380v,460v,3phase
Total power:5.5KW
Maximum cylinder stroke :150mm
Oil cylinder effective stroke :150mm Output pressure:5T
Mode control mode:manual button + mechanical limit
Start mode:hands button
Cooling system:air cooling
Hydraulic oil number: 68#
Machine size:700*650*1800mm
Machine weight:500kg
Parameters:
Structural material of stainless steel 304 alloy aluminum
The area of the working platform is 600 * 600mm
Using voltage:220v,380v,460v,3phase
Total power:5.5KW
Maximum cylinder stroke :150mm
Oil cylinder effective stroke :150mm
Output pressure:5T
Mode control mode:manual button + mechanical limit
Start mode:hands button
Cooling system:air cooling
Hydraulic oil number: 68#
Machine size:700*650*1800mm
Machine weight:500kg
