Applying:
This machine is our company specially developed a tablet press for pressing effervescent tablets, in view of the strong viscosity, demoulding difficult pill, adopt unique demoulding way, to ensure that the pressed out tablet is bright and clean, beautiful, beautiful, is the production of effervescent tablets, viscous strong ideal disinfectant tablet devices.
this model is good for adhesion, high humidity, poor liquidity, easy to be affected with damp be affected with damp powder with special design;
Features:
The machine designed for full closed structure,it has the advantage of running stable,high efficiency,lower energy consumption etc.
The machine rack adopt the stainless steel,the surface be treated by polishing,meet the GMP standard.
The machine adopt the transparent plastic window,can see the tablet producing clearly,the window can be opened for clearing and maintenance. Adopt the frequency control and with the hydraulic system,the pressure is very big,the pressure can be adjust.
Has the over loading protect,make sure the machine safe
The transfer system with electromagnetic clutch ,it is independent with the pressing chamber,can prevent pollute the product,the electromagnetic clutch also can prevent the machine over load and make adjust the machine more easy.
All punching mold and other wearing part can be universal with other model press machine
Parameter:
| Max pressure | 80T |
Max.Filling Depth | 15mm |
Max.Pressure Diameter | 22mm |
Max.Tablet Thickness | 10mm (can customize) |
RPM | 1400(r/min) |
Working Capacity | 21000(pcs/h) |
Power supply | 3KW 380V 50HZ(220V 50HZ) |
Overall Dimension | 800*1000*1500mm |
Weight | 1000kg |
Competitive advantage:
1. We have several technicians who gets passport ready to travel all over world to offer service to you.
2. We have 24hours hot line for Technical Support.
3. We get 18hours internet line for technical support.
4. Video camera in workshop to help you adjust and solve machine problem in working situation.
5. We have Technical Support in below Country:
USA (Distributor ),Italy distributor,Britishi(Distributor),India(Distributor)
Comany info:
We are mainly produce the pharma machine,pharma packing machine,and disposable non-woven take care product machine.Our product includes capsule filling machine,tablet press machine,powder mixing machine,powder grinding machine,tablet capsule counting machine,blister packing machine,cartoning machine,labeling machine,face mask machine,shoe cover machine,bouffant cap machine,body wamer pad machine,eye warmer pad machine,sheet bed machine,non-woven sheet folding machine,non-woven slitting machine,etc all kind of non-woven product machine.
