Applying:
The machine is designed and further improved on the base of original full automatic capsule filling machine from both home and aboard. With high technology and exclusive performance, it has reached international leading level.
It is an ideal equipment for capsule and medicine in pharmaceutical industry which is in full compliance with GMP requirements.
Feature:
It adopted PLC programmable controller, step-less frequency inverter, man-machine interface to operate and touch screen display With fault or lack of material, the machine will automatically alarm and shut down, and eliminate automatic alarm after troubleshooting.
Good-looking appearance, exquisite workmanship, eases of operation, simplicity of use.
Filling seat and measuring plate are designed as one unit to make measuring plate and filling rod without deviation, avoid friction between filling rod and measuring plate, improve its precision, furthermore, it enhances the machine’s life greatly.
Ineligible capsule can be eliminated automatically, the medicine in the capsule can be recycled and be reused, thus it can improve greatly the economic efficiency.
Simplicity and convenience of dismantling, installation and clean, various models of mould can be replaced
Parameters:
MODEL | NF-520 |
Filling Dosage | Powder, Pellets, Tablet,Oil |
Capsule Size | Capsule size 000#-5# and safety capsule A-E |
Max Output (capsules/hour) | 31200 |
Power | 380V 50Hz 3KW |
Noise Index | <80dBA |
Overall Dimension (mm) | 1100×1000×1900 |
Weight (kg) | 1000 |
